| Shaft diameter (dr) | 50 mm | +13/-2 µm |
| Outer diameter (D) | 75 mm | 0/-13 µm |
| Length (L) | 100 mm | 0/-300 µm |
| Groove distance (B) | 77.6 mm | 0/-300 µm |
| Groove distance (W) | 2.65 mm | |
| Groove diameter (D1) | 72 mm | |
| Opening width (h1) | 21 mm | |
| Angle (α) | 50 ° | |
| Number of ball row | 5 | |
| Eccentricity | 17 µm | |
| Load rating dynamic (C) | 3820 N | |
| Static load rating (C0) | 7940 N | |
| Operating temperature | -20 / +110 °C |
